ABS 30 cu. ft. Capacity Standard Hazardous Location Refrigerator ABT-HC-ERS-30
This 30 cu. ft. hazardous location refrigerator is meticulously engineered for the safe and reliable storage of volatile materials in potentially hazardous work environments. It’s the ideal choice for industrial environments requiring strict safety protocols. This unit utilizes EPA SNAP compliant natural refrigerants for environmentally responsible operation. Maintaining a consistent temperature range of 2°C to 10°C with tight temperature uniformity, this refrigerator provides dependable cold storage backed by microprocessor technology. It features a durable white powder-coated steel exterior, with a keyed door lock for added security. Adjustable interior shelving allows for versatile organization. With low energy consumption and precise temperature control, the ABT-HC-ERS-30 is a safe and efficient solution for hazardous laboratory locations and industrial settings.
Details
| Storage capacity (cu. ft) | 30 Cu. Ft. |
| Door | One solid swing, right hinged; stainless steel door handle; magnetic door gasket |
| Shelves
Drawers |
Five adjustable
Non-applicable |
| Mounting and Installation | Leveling Legs |
| Interior lighting | Non-applicable |
| Airflow Management | Forced draft circulation |
| External probe access | 3/4″ probe access port on rear wall |
| Insulation | EPA compliant high density urethane foam |
| Exterior materials | Powder coated steel |
| Access control | Keyed Door Lock |
| General warranty | Two (2) year parts and labor warranty |
| Compressor warranty | Five (5) year compressor parts warranty |
| Product Weight (lbs) | 320 |
| Shipping Weight (lbs) | 350 |
| Rated Amperage | 3.1 Amps |
| Facility Electrical Requirement | 110 – 120V AC, 15A breaker, NEMA 5-15 receptacle |
| Agency Listing and Certification | UL and c UL listed, Meets NFPA and OSHA guidelines for Hazardous locations, Class 1, Division II, Groups C & D |
Performance
| Uniformity (Cabinet air) | +/- 1.6°C | |
| Stability (Cabinet air) | +/- 1.5°C | |
| Maximum temperature variation
(Cabinet air) |
4.6 °C Total | |
| Energy Consumption (KWh/day) | < 1.5 KWh/day | |
| Average Heat Rejection (BTU/hr) | 500 BTU/hr | |
| Pull down time to nominal operating temp |
|
|
| Width (in.) | 35.75″ | |
| Depth (in.) | 35.5″ | |
| Height (in.) | 72.5″ | |
| Refrigerant | EPA SNAP compliant R600a Isobutane |
Temp Controller
| Controller technology | Microprocessor temperature controller | |
| Temperature Setpoint Range Notes | Minimum temperature limited to avoid freezing | |
| Refrigerant | EPA SNAP compliant R600a Isobutane | |
| Condenser | Static – exterior walls of cabinet | |
| Evaporator | Fin and tube design, high efficiency fan, hazardous location rated | |
| Display Probe | Product simulator bottle with glass bead media | |
| Adjustable Temperature Range | 2°C to 10°C | |
| External alarm connection | Remote alarm contacts | |
| Alarms | Audible and visual high/low-temperature alarms, Door ajar alarm, Remote alarm contacts | |
| Disclaimers |
|
