Product Overview

This ACCU-SCOPE 40×R Plan Phase Contrast dry objective is designed for compatible infinity-corrected microscopes, enabling phase-contrast examination of suitable transparent specimens.

Key Features

• Magnification: 40×R
• Numerical aperture: 0.65
• Working distance: 0.72 mm
• Immersion: dry
• Optical design: Infinity Plan Phase Contrast
• Coverglass: No. 1½
• Mounting: RMS thread

What Is This Objective Used For?

• Phase-contrast microscopy of unstained specimens
• Laboratory slide examination and documentation
• Replacing or expanding compatible objective sets

Technical Specifications

Compatibility & Ordering

Designed for ACCU-SCOPE models listed in the original product specifications below. Olympus CX/BX compatibility is mentioned in the original listing, but parfocality is not guaranteed. Phase-contrast use also requires the appropriate matching phase annulus and condenser. Confirm all compatibility before ordering.

Manufacturer Resources

Official ACCU-SCOPE manufacturer resources

Additional Product Details

This microscope objective is compatible with Olympus CX and BX microscopes.  Although it will not be 100% parfocal

Specifications

• 40xR Plan Phase Contrast objective
• N.A. 0.65
• Working distance 0.72mm
• Provides a flat field of view
• Infinity corrected
• Corrected for No. 1 ½ coverglass
• Spring-loaded bottom lens to prevent damage to the objective and the specimen
• RMS threads
• Designed for 3000-LED, EXC-350 and 3000 series microscopes
• Shipping size 9x7x5 inches
• Shipping weight 1lb
