Scilogex Foam SCI40-Pro (40L) LCD Digital Overhead Stirrer 50-2200rpm

Regular price $1,191.00
Don't see the option you are looking for? Call 919-775-5596

Follow Us Online!

For an official Quote Email us at info@mundaymicroscope.com

Have questions or need Faster Shipping? Call 919-775-5596

SCILOGEX SCI40-Pro (40L) LCD Digital Overhead Stirrer 50-2200rpm 840203019999

SCILOGEX Overhead Stirrers can accomplish the most demanding tasks and provide high safety and increased performance. They are widely used in chemical synthesis, pharmaceutical synthesis, physical and chemical analysis, petrochemical industries, etc.

  • Accurate microprocessor stirring speed control guarantees speed precision
  • High reliability and outstanding performance
  • Anti-spill microprocessor control slow start up prevents accidental spillage and splashing
  • Remote function provide PC control and data transmission
  • Availability of auto-restart function in case of power loss for overnight operations.
  • A through-shaft design allows for easy adjustment of the impeller position
  • Large chuck diameter for many shaft types
  • Brushless DC motor for long life, maintenance free and explosion proof
  • Provides constant speed even with changes in viscosities of the samples
  • LCD display for precise monitoring of set and actual speeds, a wide range of speed from 50 to 2200rpm with control accuracy of ±3rpm. Set value and actual value can be displayed for real-time monitoring of torque and speed
  • Over torque protection automatically stops the motor
  • Torque trend display for real-time information on viscosity changes
  • Safety circuits allow for safe stop function in anti-stall or overload conditions
  • Pass through stirrer rods accepted
  • Keyless chuck
  • PC software control via RS232 interface, for control and documenting all measured values via PC.
  • cTUVus approved for UL and CSA
  • 2 YEAR WARRANTY
Maximum stirring capacity 40 Liters
Maximum torque 60Ncm
Viscosity maximum 50000mPas
Speed range 50-2200rpm
Speed display accuracy ± 3rpm
Speed display resolution ± 1rpm
Chuck diameter range 0.5-10mm
Dimensions 3.3W x 8.7H x 7.3D inches (83W x 220H x 186D mm)
Motor rating input 120W
Motor rating output 100W
Weight 5.5lbs
Motor type brushless DC motor
Voltage/Power 100-220V, 50/60 Hz/ 130W
Speed/Torque display LCD
Overload protection display LED lights
Protection class IP21
Data connector RS232
Permissible ambient temperature and humidity 5-40°C, 80%RH
