Memmert Vacuum Ovens VO101

Digital pressure control ensures rapid and gentle vacuum drying. Its speed-controlled vacuum pump (accessory) saves around 70% energy.

FEATURES

• STAINLESS STEEL
• ATMOCONTROL
• 3 YEAR WARRANTY
• TWINDISPLAY

Temperature Specs:

• Temperature measured through 4-wire Pt100 sensor individually for each thermoshelf
• Working Temperature Range: min. 5°C above ambient up +200°C
• Setting temperature range: +20°C to +200°C

Pressure Specs:

• Vacuum range: 5 to 1100 mbar
• Pressure control: Digital electronic pressure control for a speed-controlled vacuum pump. Tubing for vacuum and air are made of material 1.4571 (ASTM 316 Ti). Programmable, digitally controlled inlet for air.
• Permitted final vacuum: 0.01 mbar
• Maximum leakage rate: 0.01 bar/h
• Pump control: speed control, optimized rinsing procedures for the pump membranes as well as signal for pump ON/OFF
• Connection: Vacuum connection with small flange DN16, and gas inlet with small flange DN16

Control Technology:

• Adjustable Parameters: Temperature (Celsius or Fahrenheit), pressure (vacuum), timer
• Language Setting: German, English, Spanish, French, Polish, Czech, Hungarian, Italian
• ControlCOCKPIT: TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-color displays.
• Timer: Digital backwards counter with target time setting, adjustable from 1 minute to 99 days
• Function SetpointWAIT: the process time does not start until the set temperature is reached

Safety:

• Temperature control: Mechanical temperature limiter TB, protection class 1 according to DIN 12880 to switch off the heating approx. 10°C above nominal temperature
• AutoSAFETY: Additionally integrated over- and undertemperature protection “ASF”, automatically following the setpoint value at a preset tolerance range, alarm in case of over- or undertemperature, heating is switched off in case of overtemperature, compressor in case of undertemperature
• Auto diagnostic system: Integral fault diagnostics for temperature and humidity control
• Alarm: visual and acoustic

Electrical data

230 Volts

• (± 10%)
• 50/60 Hz
• Approx. 10.5 amps @ 230V

Stainless Steel Interior:

• Material: hermetically welded stainless of extremely corrosion-resistant stainless steel, material 1.4404
• Interior: additional interior mountings of stainless steel, material 1.4404 (removable for cleaning), consisting of mounting at the sides with guide bars for thermoshleves and on top (diffusor) to avoid turbulences when aerating
• Volume: 101 I
• Dimensions: w x h x d : 21.5” x 18.3” x 15.7”
• Max. number of internals: 4
• Max. loading of chamber: 132 lbs
• Max. loading per internal: 44 lbs

Stainless Steel

For many years exterior textured stainless steel has been the unmistakable feature of Memmert ovens, incubators, and climate chambers in laboratory and light-industrial settings. Memmert equipment exemplifies functional design in its most elegant and hygienic form, while still being scratch resistant, robust and durable.

Stainless steel is the ideal material for temperature control chambers and heating baths. It is particularly corrosion-resistant, hygienic, robust and recyclable without question.

Wherever Memmert ovens and heating baths are used, the superiority of high-quality stainless steel is undeniable in comparison to others that utilize coated sheet steel, which can corrode very quickly when in constant use.

For the outer housing of all Memmert appliances, textured stainless steel is used (rear walls are zinc-plated sheets). The inner chamber, sliding shelves/grids, housing, interior basin and accessories for every heating bath, stainless steel of class W-St. 1.4301 (ASTM 304) is used. Since aggressive substances are frequently used in the vacuum drying oven, the inner chamber and thermoshelves are made of stainless-steel W-St. 1.4404 (ASTM 316L), and the tubing is made of stainless-steel W-St. 1.4571 (ASTM 316i).
