Mitutoyo 10x M Plan APO UV Objective

Regular price $11,340.00
Don't see the option you are looking for? Call 919-775-5596

Follow Us Online!

For an official Quote Email us at

Have questions or need Faster Shipping? Call 919-775-5596

Mitutoyo 10x M Plan APO UV Objective - 378-844-5. This long working distance objective is ideal for use in visible (550nm) and the ultraviolet (266nm) regions of the spectrum.

Type: Infinity Corrected Brightfield
Wavelength: Visible & UV
Magnification: 10x
N.A.: 0.25
Working Distance: 20mm
Wavelength Range: 266nm and 550nm
Focal Length UV Radiation: 20mm
Focal Length Visible Radiation: 20.3mm
Resolving Power: 1.1µm
Focal Depth:
Field of View with Ø24 Eyepiece Ø2.4
Real Field of View with 1/2" Chip Camera 0.48 x 0.64
Thread Size: M26
Part Number: 378-844-5
