Motic GM-171 Trinocular Gemological Stereo Microscope
Couldn't load pickup availability
Follow Us Online!
For an official Quote Email us at info@mundaymicroscope.com
International Buyers - Please Request Quote with ship to address
Have questions or need Faster Shipping? Call 919-775-5596
The Motic GM-171 is a stereo zoom microscope designed for gemological inspection and precious-stone evaluation. Its zoom optics and gemological stand help users examine surface characteristics, inclusions, and other visual features under different lighting conditions.
Key Features and Applications
- 7.5X–50X stereo zoom magnification in the listed standard configuration
- Trinocular observation for compatible camera attachment
- Brightfield and darkfield viewing on the gemological stand
- Designed for gemologists, jewelers, and mineral examination
Refer to the original technical specifications below for exact configuration, included components, and optional accessories.
Motic GM-171 is the scope for gemological and precious minerals work. Having a 7.5X-50X stereo zoom head with modern Brightfield/Darkfield gem stand, the scope allows quick and easy analysis of samples.
Specifications
| Optical system | Greenough | ||
| Observation tube | Binocular head | ||
| Inclination | 45º inclined | ||
| Interpupillary distance | 52-75mm | ||
| Diopter adjustment | On both eyepieces, +/- 5 diopter | ||
| Eyepieces | Widefield WF10X/23mm | ||
| Objectives system | Zoom, ratio 6.7:1 | ||
| Objectives | 0.75X~5X | ||
| Working distance | 110mm | ||
| Stand type | 360º rotary base | ||
| Diaphragm | Iris diaphragm, adjustable aperture Ø41mm - Ø2mm | ||
| Head holder | For Ø76mm head | ||
| Focus mechanism | Coarse focusing system with tension adjustment | ||
| Focusing stroke | 125mm | ||
| Incident illumination | Fluorescent 7W with Gooseneck adjustable | ||
| Transmitted illumination | Quartz Halogen 6V/30W with intensity control | ||
| Illumination features | Darkfield illuminator | ||
| Transformer | Internal | ||
| Power supply | 100-240V (CE) | ||
| Accessories included | Dust cover, stainless steel wire stone holder, aluminium carrying case | ||
| Dimensions | LxWxH 391x236x505mm | ||
| Base | 306x236mm | ||
| Column/Arm Height | 268mm, 45º tilting arm | ||
| Net weight | 8.2kg | ||
