| Model |
S1 |
S3 |
S6 |
S12 |
S20 |
Pro S5 Lite |
Pro S5 Plus |
| Sensor Type |
sCMOS
|
| Sensor Size |
1/3" |
1/2.8" |
1/1.8" |
1/1.7" |
1" |
2/3" |
2/3" |
| Imaging Area |
6.09mm (Diagonal) |
6.44mm (Diagonal) |
8.92mm (Diagonal) |
9.33mm (Diagonal) |
15.86mm (Diagonal) |
11.1mm (Diagonal) |
11.1mm (Diagonal) |
| Capture Resolution Info |
1.2MP |
3MP |
6MP |
12Mp |
20MP |
5MP |
5MP |
| Live display mode through USB (pixels) |
1280x960, 640x480 |
2048x1536, 1920x1080 |
3072x2048, 1536x1024 |
4000x3000, 2048x1080 |
5472x3648, 2736x1824 |
2448x2048, 1224x1024 |
2448x2048, 1224x1024 |
| Pixel size |
3.75x3.75μm |
2.5x2.5μm |
2.4x2.4μm |
1.85x1.85μm |
2.4x2.4μm |
3.45x3.45μm |
3.45x3.45μm |
| Scan mode |
Progressive
|
| Shutter mode |
Rolling Shutter |
Rolling Shutter |
Rolling Shutter |
Rolling Shutter |
Rolling Shutter |
Global Shutter |
Global Shutter |
| Data transfer |
USB 3.1
|
| Max. frames per second (fps*) |
1280x960 @ 120fps, 640x480 @ 240fps |
2048x1536 @ 60fps, 1920x1080 @ 60fps |
3072x2048 @ 30fps, 1536x1024 @ 50fps |
4000x3000 @ 25fps, 2048x1080 @ 50fps |
5472x3648 @ 18fps, 2736x1824 @ 50fps |
2448x2048 @ 37.5fps, 1224x1024 @ 88.4fps |
2448x2048 @ 68.3fps, 1224x1024 @ 175.8fps |
| Exposure time |
15 μsec to 2 sec |
21 μsec to 2 sec |
16 μsec to 2 sec |
22 μsec to 2 sec |
15 μsec to 2 sec |
14 μsec to 2 sec |
7 μsec to 2 sec |
| Operating temperature |
From -10 to +60 Degrees Celsius non condensing
|
| Sensitivity |
2350mV(G) @ 1/30 sec |
600mV(G) @ 1/30 sec |
425mV(G) @ 1/30 sec |
280mV(G) @ 1/30 sec |
461mV(G) @ 1/30 sec |
1146mV(G) @ 1/30 sec |
1146mV(G) @ 1/30 sec |
| Support device |
TWAIN, SDK and DirectShow Driver
|
| Supported OS |
Microsoft Windows 7/8/10, MAC OSX, Linux or higher
|
| Minimum computer requirements |
2GHz dualcore - RAM memory 2GB - Video memory min. 512 MB
|
| Lens mount |
C-Mount
|
| Software |
Motic Images Plus 3.0 for Windows, OSX and Linux
|
| Functions |
Still image and video capture, live and still image measurement, image adjustments, white balance, automatic & manual exposure, individual objective calibration system
|
| Power supply |
5V (from USB Port)
|
| Package includes |
CS ring adaptor, USB 3.1 cable, Motic 4-dot calibration slide, Motic Images Plus 3.0 for Windows/OSX/Linux
|
| (*) Frames per second under optimal lighting conditions and in compliance with computer technical requirements. |
