Product Overview

The Omni 3 Measurement App Bundle combines 2D measurement, graticule and annotation tools with Z-height measurement for compatible Omni 3 systems.

Key Features

• 2D measurement, graticules and annotation
• Z-height measurement
• Combined inspection workflow

What Is This Product Used For?

• Dimensional inspection in X, Y and Z
• Go/no-go inspection and annotation

Technical Specifications

Compatibility & Ordering

Verify your microscope model, installed software and required application licenses before purchasing. This app is intended for Omni 3 and is not compatible with older OMNI or OMNI Core systems.

Manufacturer Resources

UNITRON manufacturer resources

Additional Product Details

Specifications

• Omni 3 Measurement App Bundle (not compatible with Omni or Omni Core)
• Includes both 2D Measurement, Graticules & Annotation App (CAT # 148-001) and Z Height Measurement App (CAT # 148-008).
• 2D Measurement App:
• Intuitive on-screen full 2D measurement application.
• Point-to-point, diameter, angle, adjustable X-Y grid, shapes and annotation features to accommodate a multitude of samples and specifications.
• Graticule creation allows rapid sample analysis against on-screen digital templates with tolerance limits, enabling quick go/no-go defect analysis.​
• Z Height Measurement App:
• Measure in the Z axis (height), in addition to the X and Y axes.
• Rapidly inspect parts up to five times faster than compared to outdated manual inspection methods.​
