4K CMOS Camera with HDMI and USB3.0 Double Performance

The TrueChrome 4K Pro offers a new dual-channel mode of microscopic imaging. It not only inherits the shortcut functions from Tucsen HDMI CMOS Cameras but also perfectly transplants Tucsen USB 3.0 camera professional functions like imaging control, image process, live stitching and live EDF, etc.

Specification
Model: TrueChrome 4K Pro
Sensor Type: CMOS
Sensor Model: IMX485LQJ-C
Color/Mono: Color
Array Diagonal: 13.33mm（1/1.2）
Resolution: 8MP, 3840(H) x 2160(V)
Pixel Size: 2.9 μm (H) × 2.9 μm (V)
Effective Area: 11.1mm x 6.3mm
Shutter Mode: Rolling
Frame Rate: 30fps@USB 3.0, 30fps@HDMI, 30fps@LAN
Exposure Time: 0ms~1S
SD Format: FAT32
Color Temperature: 1800-10000K
Software: HDMI: Cloud 1.0 Ver USB: Mosaic V2
HDMI Key Settings: Preview: 3840x2160, Capture: 3840x2160, Vedio recording: 30fps@3840x2160
Picture Format: HDMI: JPG/TIF USB: TIFF/JPG/PNG/DICOM
Multiple Cameras: Supports 4 Cameras Simultaneously in SDK
Optical Interface: Standard C Mount
Data Interface: HDMI, USB3.0, USB2.0, LAN
Operating System: Windows 7/10 (32 Bit/64 Bit)/Mac
PC Configuration: CPU: Intel Core i5 or better(Quad or more Core), RAM: 8G or more

Efficient image acquisition - editing - measurement - report output
From the user's point of view, redefining the image acquisition - editing - measurement - report output workflow process, taking into account the best operating procedures, greatly saves the operating time, effectively improving productivity.

Excellent imaging performance for brightfield, fluorescence and polarized imaging needs
The use of Tucsen's core ISP color-interpolation algorithm effectively corrects the color deviation of the sensor's spectral response, to simulate the human eye's sensitivity to color. The true color in the eyepiece, whether it is a biological bright field, stereo or fluorescence image.

Software: Mac , Windows

Tucsen Camera Quick Start Guide
