Yamato DG-450C Natural Convection Glassware Drying Oven with Sterilization Lamp (220V)
Couldn't load pickup availability
Follow Us Online!
For an official Quote Email us at info@mundaymicroscope.com
International Buyers - Please Request Quote with ship to address
Have questions or need Faster Shipping? Call 919-775-5596
Yamato DG450C 3.2 Cu Ft. (92L 220V) Glassware Drying Oven with Sterilization Lamp
Natural convection oven and sterilization lamp for glassware drying.
Operation and functions
- Large window for easy observation
- Can be used to store instruments after drying
- Highly efficient heat insulation material for both internal and external structure
- Adjustable foot for stability on uneven floors
- Mobile on casters (DG800C/810C/840C/850C)
- Equipped with stainless steel pipe heater and water receiving plate at the bottom
- Stainless steel interior, easy to clean and highly resistant to corrosion
- DG440C/450C/840C/850C installed with filter at air in-take port, exhaust fan and germicidal lamp for fast drying
- Dial setting and digital display of temperature control and timer
Safety features
- Self-diagnostic functions, calibration offset, independent overheat prevention, over current leakage breaker, key lock and auto recovery after power failure
Specifications
| System | Natural convection |
| Operating Temp. Range | RT+5~70°C |
| Interior Material | Stainless steel |
| Temp. Setting Method | Digital setting by ▲/▼ keys |
| Heater | SUS pipe heater 1.0kW |
| Temp. Controller | PID control with microprocessor |
| Operation Functions | Fixed temperature, auto stop, auto start, quick auto stop |
| Sensor | Temp. controller: K thermocouple, Overheat protection: Liquid-expansion temp. controller |
| Exhaust Port | I.D. 34mm × 2 |
| Suction Port | I.D. 30mm × 2 |
| Germicidal Lamp | None |
| Internal Dimensions WxDxH | 450×450×450 mm |
| External Dimensions WxDxH | 504×562×788 mm |
| Internal Capacity | 92L |
| Weight | 45kg |
| Door | Single door, silicon rubber packing |
| Observation Window | Standard glass 3mm W250 x H300mm |
| Shelf Plate Load | 15kg/pc. |
| Shelf Rest / Pitch | 10 steps / 30mm |
| Power Source | AC115V , AC220V |
| Shelf Plate / Bracket | 2pcs. / 4pcs. |
| Water Receiving Plate | 1pc. |
This product ships directly from Yamato, ensuring fast delivery, proper handling, and factory quality. When you purchase Yamato, you’re backed by a trusted name in laboratory equipment—known for precision, reliability, and dependable support. Shop with confidence knowing your order is fulfilled directly by the manufacturer.
