Yamato Distilled / Deionized Water Purification System ~5L/Hr. 100L Tank 20V Single Phase WG-1012
Couldn't load pickup availability
Follow Us Online!
For an official Quote Email us at info@mundaymicroscope.com
International Buyers - Please Request Quote with ship to address
Have questions or need Faster Shipping? Call 919-775-5596
Yamato Distilled / Deionized Water Purification System ~5L/Hr. 100L Tank 220V Single Phase WG-1012
Units do not come with ion-exchange resin cartidge. Must be purchased separately.
Yamato’s Auto Still multi-purpose water purification system come standard with water intake membrane filters to increase the life span of all consumables and a 30L(WG252) or 100L (WG1012) large storage tank capacity. The standard equipped membrane filters at feeding port protect pure water production from contamination. The WG series produces ASTM deionized water type 1 and type 2 distilled water kept in a 30L or 100L storage tank.
Features
- Two independent dispensers for water sampling
- 7-inch LCD touch panel system
- Consumable management functions
- Trend graph
- Easy replacement of ion-exchange resin
- Large distilled water tank with capacity of 30L (WG252) and 100L (WG1012)
- Easy to use slide out type water sampling tray with drainage eliminates concerns about overflowing water discharge
Specifications
| Water Purifying Method | Ion exchange→Distillation→Filtration | |
| Purified Water | Deionized water and distilled water | |
| Distilled Water Production | ~5L/h | |
| Distilled Water Delivery Rate | ~2.5L/min (with variable flow rate function) | |
| Deionized Water Delivery Rate | ~1.0L/min (with variable flow rate function) | |
| Range Of Production | 0.1~100L / continuous water collection | |
| Condenser | Hard glass | |
| Heater | Ceramic heater 1.9kW x 2 | |
| Pre-Treatment Cartridge | 0.1µm hollow fiber + activated carbon (PWF-1) | |
| Ion-Exchange Resin Cartridge | CPC-S 4L x 2pcs.(activated carbon high-purity cartridge) | |
| Final Filtration | 0.1µm membrane filter x 2 | |
| Leakage Detection | Water leakage detector forcefully shuts off feed water solenoid valve when water leakage detected | |
| Distilled Water Tank Capacity | 100L polyethylene tank | |
| Distilled Water UV Sterilization | Optional | |
| Water Sampling Tray | Slide out type, load-bearing capacity 10kg, for 5L beaker | |
| Multi-Purpose Distilled Water Sampling Port | For connecting Φ8 hard tube (right side of main body) | |
| Raw Water Pressure Range | 0.1-0.5 MPa | |
| Distilled Water Tank Full Water Setting | 10, 30, 60, 90L | |
| Power Source (50/60 Hz) | AC220V 18A | |
| External Dimension*¹ | W550 x D570 x 1715 mm | |
| Weight | ~113kg | |
| Water Level Display | LED display | |
| Water Quality Display | Digital (conductivity or resistivity) | |
| Other Display | Notification: Consumables replacement / Periodic maintenance, Alarm: Water outage / Trend data recording impossible / Power failure / Distilled water quality deterioration, Abnormality: Controller / Water leakage / Heater overheating / disconnection / Tank water level gauge / Boiler water level, Water level gauge / Boiler drainage route / Cooling water / Water quality meter / Water sampling pump, / Ion exchange water flow reduction / Water sampling route | |
| Accessories | 1 water supply hose (2 m), 1 water supply hose filter, 1 connection hose assembly, 1 can stone cleaner, 1 pretreatment cartridge, 1 ion exchange resin cartridge, 1 air vent filter, 2 membrane filters , 2 filter covers, 2 magnet hooks | |
This product ships directly from Yamato, ensuring fast delivery, proper handling, and factory quality. When you purchase Yamato, you’re backed by a trusted name in laboratory equipment—known for precision, reliability, and dependable support. Shop with confidence knowing your order is fulfilled directly by the manufacturer.
