Yamato Water System With 0.2 Micron Capsule Filter WA-401
This system provides 4L per minute of 18.2 megohm water. A quiet recirculation pump ensures constant water purity. Water quality meets or exceeds ASTM Type I water specifications.
Features
- Made in USA
- Low-cost of Ownership
- Compact design
- Quick change, cartridge – no tools needed
- 4 LPM* of 18 MΩ Type 1 reagent water on demand
- Replacement cartridges are fresh and made in the USA. 1 year shelf life.
WA Series Configuration
- Built-in pressure regulator
- 0.2 micron filter
Specifications
| Influent Quality | |
| Source | Reverse Osmosis, DI or Distillation |
| Purity | < 20 uS/cm |
| Filtration | 0.2 micron |
| Free Chlorine | < 0.05 ppm |
| Silica | < 2 ppm |
| TOC | < 50 ppb |
| Effluent Quality (Standard System) | |
| Purity | > 18 Megohm- cm |
| Microorganisms | < 10 CFU / mL |
| Chlorides | < 1 ppb |
| Sodium | < 1 ppb |
| With 0.05 Micron UF Endotoxin | < 0.03 EU |
| Technical Data | |
| Pressure | 90 PSIG Maximum 20 PSIG Minimum |
| Temperature | 100˚F / 30˚C |
| Flow Rate | 4.0 lpm (1.1 GPM) 2.0 lpm (0.53 GPM) with capsule filter |
| Connections | Inlet 3/8” Tube Outlet 1/4” FNPT |
| Dimensions (H X W X D) | 25 in. x 23 in. x 8.5 in. (64 cm x 59 cm x 22 cm) |
| Weight | 32 lbs dry / 38 lbs operating (14.5 kg dry / 17.3 kg operating) |
| Outer Shell | Powder coated steel |
| Power Requirements | 120V, 60 Hz @ 1.0 amp |
| Options | Remote dispensing gun, 0.05 micron hollow fiber UF filter, combination high-purity/sub-micron cartridge, Reverse osmosis, direct feed option for auxiliary equipment |
This product ships directly from Yamato, ensuring fast delivery, proper handling, and factory quality. When you purchase Yamato, you’re backed by a trusted name in laboratory equipment—known for precision, reliability, and dependable support. Shop with confidence knowing your order is fulfilled directly by the manufacturer.
