Unitron Z650HR Trinocular High Resolution Zoom Stereo Microscope On LED Incident & Transmitted Focusing Stand

Regular price $2,586.00
Don't see the option you are looking for? Call 919-775-5596

Follow Us Online!

For an official Quote Email us at info@mundaymicroscope.com

Have questions or need Faster Shipping? Call 919-775-5596

Trinocular High Resolution Zoom Stereo Microscope
On LED Incident & Transmitted Focusing Stand
Trinocular viewing head, 0.6x to 5.0x zoom range, inclined at 30°,115 mm working distance,
interpupillary distance adj, 52-75mm, glass lens shield
WF 10x eyepieces with built-in diopter adjustment (paired) 23mm field of view, 0/100 light split,
with 0.55x built-in c-mount lens, or remove to become a 1x c-mount
Variable LED incident (12v/2w) and transmitted (12v4w) focusing stand with stage clips,
universal power supply
100mm Frosted, clear glass, black & white stage plates
Dust cover and instruction manual

Specifications

  • Trinocular viewing head inclined at 30°
  • 0/100 light split
  • Built-in 0.55x c-mount camera adapter
  • Widefield 10x/23mm focusing eyepieces with roll down eyeguards
  • 0.6x – 5.0x zoom magnification range
  • 8:1 zoom ratio
  • Magnification range 6x-50x (with 10x eyepieces), with click stops at 1x, 2x, 3x, 4x and 5x
  • Interpupillary Distance Adjustment 55mm – 75mm
  • 115mm working distance
  • LED stand with variable LED incident (12v/2w) and transmitted (12v4w) illumination
  • Focusing stand with stage clips
  • Universal power supply 100v to 240v
  • 100mm Clear glass, black & white stage plates
  • Airtight and anti-mold design
  • Shipping weight 16lbs.
