Unitron Z850 Zoom Stereo Microscope, Binocular, Articulating Arm Stand, 0.5x Aux Objective, Quad LED Ring Light
Couldn't load pickup availability
Follow Us Online!
For an official Quote Email us at info@mundaymicroscope.com
International Buyers - Please Request Quote with ship to address
Have questions or need Faster Shipping? Call 919-775-5596
Product Overview
The UNITRON Z850 zoom stereo microscope provides detailed three-dimensional observation for inspection, quality control and precision assembly. This configuration uses a flexible articulating arm and includes a 0.5× auxiliary objective for increased working clearance.
Key Features
- Zoom: 0.8×–5.0×
- Magnification with 10× eyepieces: 4×–25× with included 0.5× objective
- Working distance: 211 mm
- Stand: Articulating flex-arm with C-clamp
- Included illumination: Quadrant LED ring light
What Can This Microscope Be Used For?
- Electronics and small-component inspection
- Industrial quality control and precision assembly
- Inspecting larger workpieces with extended working distance
Technical Specifications
| Zoom | 0.8×–5.0× |
|---|---|
| Magnification with 10× eyepieces | 4×–25× with included 0.5× objective |
| Working distance | 211 mm |
| Stand | Articulating flex-arm with C-clamp |
| Included illumination | Quadrant LED ring light |
Compatibility & Ordering
Confirm the selected optical head and camera accessories before ordering. Excelis HDS and HDS Lite cameras are not recommended for the Z850 series.
Manufacturer Resources
UNITRON official microscope information
Additional Product Details
The Unitron Z850 Series with a 6.3:1 zoom ratio is an ideal choice for industrial inspection, assembly, quality control, OEM integration, research and education applications requiring a higher magnification range.
The Z850 Series is a versatile, high performance, ergonomically designed zoom stereo microscope ruggedly built to withstand years of heavy usage.
Specifications
- Binocular viewing head with 45° viewing angle
- Widefield 10x/22mm focusing eyepiece. 22mm Field of View.
- 0.8x – 5.0x zoom magnification range
- 6.3:1 Zoom ratio
- Magnification range 4x-25x (with 10x eyepieces and included 0.5X auxiliary objective), with click stops at 1x, 2x, 3x, 4x and 5x
- Interpupillary Distance Adjustment 52mm – 75mm
- Field of view 55mm - 8.8mm
- 211mm working distance
- Includes Quadrant LED ring light (CAT # 15858) with external intensity and quadrant control
- Articulating Arm with lockable 14.5” vertical motion range and 3’ scannable range
- Horizontal or vertical c-clamp mount
- Bonder Arm (E-Arm)
- Airtight and anti-mold design
- Shipping weight 25lbs.
